Merge branch 'main' of gitlab.ec-lyon.fr:epsa-personnal-git/epsa-pae-ai-self-driving

Documentation/Projet/Simulation/2D-car-dynamics-simulation-master/README.md

+# 2D-car-dynamics-simulation
+2D car simulator

Documentation/Projet/Simulation/2D-car-dynamics-simulation-master/analysis.py

+import xml.etree.ElementTree as ET
+from track_2_generator import create_track
+from shapely.geometry import Polygon, Point, LineString
+import numpy as np
+
+from matplotlib.pyplot import plot, legend
+import json
+
+"""loading track"""
+track_points = create_track(0.5,0,0, (0,0))[:-1]+[(1,0.5)]
+track = Polygon(track_points)
+#outside_l = create_double_circles(0.59375, (0.5,0.5),(1.5,0.5))
+
+"""
+x_shift, y_shift = 1433.0000000000002, -406.0866103896103*2#Tom: 1433.0000000000002, -406.0866103896103*2 / Damien: -540, 960
+R_simu = 150#Tom: 150 / Damien: 350
+R_reel = 0.5
+x_shift, y_shift = x_shift/R_simu-4.77, y_shift/R_simu+2.7 #Tom:-4.77,2.7 / Damien: 1.88, -2.5
+"""
+
+def get_error(name, R_simu, center_x, center_y, start=-1, end=-1):
+
+    """loading trajectory"""
+    with open(name) as json_file:
+        data = json.load(json_file)
+
+    x_shift, y_shift = center_x/R_simu, center_y/R_simu
+
+    time = data["time"]
+    x_l = [(i/R_simu-x_shift)/2+1 for i in data["x"]]
+    y_l = [(i/R_simu-y_shift)/2+0.5 for i in data["y"]]
+    e_l = []
+
+    if start>=0:
+        x_l = x_l[start:]
+        y_l = y_l[start:]
+        time = time[start:]
+    if end>=0:
+        x_l = x_l[0:end]
+        y_l = y_l[0:end]
+        time = time[0:end]
+
+    for x,y in zip(x_l,y_l):
+        front_center = Point(np.array([x,y]))
+        e = track.distance(front_center)
+        e_l.append(e)
+
+    return x_l, y_l, time, e_l
+
+#plot([x for x,y in track_points], [y for x,y in track_points])
+#plot([i[0] for i in outside_l], [i[1] for i in outside_l])
+
+prefix = 'paths/'
+suffix = '_normal.json'
+Tom = get_error(prefix+'errorT'+suffix, 150, 1733, -666, 70, 450)
+Damien = get_error(prefix+'errorD'+suffix, 350, 930, 510, 25)
+plot(Damien[2],Damien[3])
+plot(*Tom[2:])

Documentation/Projet/Simulation/2D-car-dynamics-simulation-master/car_data_display.py

+import pygame
+
+
+class CarDataDisplay:
+    def __init__(self, car, track):
+        self.car = car
+        self.track = track
+        pygame.font.init()
+
+    def display_data(self, screen, position=(0, 0), font='Verdana', size=20):
+        font_color = (255, 255, 255)
+        font = pygame.font.SysFont(font, size)
+        vel_long = font.render('Long velocity: ' + str(round(self.car.velocity.x * 3.6, 2)), False, font_color)
+        vel_lat = font.render("Lat velocity: " + str(round(self.car.velocity.y * 3.6, 2)), False, font_color)
+        rpm = font.render('Engine RPM: ' + str(round(self.car.wheel_rpm * self.car.diff_ratio * self.car.gears[self.car.gear], 2)),
+                          False, font_color)
+        gear = font.render('Gear: ' + str(self.car.gear), False, font_color)
+        steering = font.render('Steering: ' + str(self.car.steering), False, font_color)
+        throttle = font.render('Throttle: ' + str(self.car.throttle), False, font_color)
+        brake = font.render('brake: ' + str(self.car.brakes), False, font_color)
+        velocity = font.render('Velocity: ' + str(round((self.car.velocity.x**2+self.car.velocity.y**2)**0.5 * 3.6, 2)), False, font_color)
+        pos_x = font.render('position.x: ' + str(self.track.car_pos[0]), False, font_color)
+        pos_y = font.render('position.y: ' + str(self.track.car_pos[1]), False, font_color)
+        track_phase = font.render('phase: ' + str(self.track.track_phase), False, font_color)
+        lap_number = font.render('lap: ' + str(self.track.lap_nb), False, font_color)
+
+        #screen.blit(vel_long, position)
+        #screen.blit(vel_lat, (position[0], position[1] + (size * 5 / 4)))
+        #screen.blit(rpm, (position[0], position[1] + 2 * (size * 5 / 4)))
+        #screen.blit(gear, (position[0], position[1] + 3 * (size * 5/4)))
+        screen.blit(velocity, (position[0], position[1] + 1 * (size * 5/4)))
+        screen.blit(steering, (position[0], position[1] + 2 * (size * 5/4)))
+        screen.blit(throttle, (position[0], position[1] + 3 * (size * 5/4)))
+        screen.blit(pos_x, (position[0], position[1] + 4 * (size * 5/4)))
+        screen.blit(pos_y, (position[0], position[1] + 5 * (size * 5/4)))
+        screen.blit(track_phase, (position[0], position[1] + 6 * (size * 5/4)))
+        screen.blit(lap_number, (position[0], position[1] + 7 * (size * 5/4)))
+        #screen.blit(brake, (position[0], position[1] + 6 * (size * 5/4)))
\ No newline at end of file

Documentation/Projet/Simulation/2D-car-dynamics-simulation-master/car_drawer.py

+from shapely.geometry.polygon import Polygon
+from shapely.affinity import rotate
+import pygame
+
+
+class CarDrawer:
+    def __init__(self, length=55, width=20, init_position=(1366/2, 768/2)):
+        self.length = length
+        self.width = width
+        self.trace = []
+        self.init_position = init_position
+        pos_x = self.init_position[0]
+        pos_y = self.init_position[1]
+        self.r_center = (pos_x, pos_y)
+
+        self.car_model = Polygon([(pos_x - self.length * 2 / 10, pos_y - self.width / 2),
+                                  (pos_x - self.length * 2 / 10, pos_y + self.width / 2),
+                                  (pos_x + self.length * 8 / 10, pos_y + self.width / 2),
+                                  (pos_x + self.length * 8 / 10, pos_y - self.width / 2)])
+
+        self.f_axle =    Polygon([(pos_x + self.length * 6 / 10, pos_y + self.width * 5 / 6),
+                                  (pos_x + self.length * 6 / 10, pos_y - self.width * 5 / 6),
+                                  (pos_x + self.length * 6 / 10, pos_y + self.width * 5 / 6)])
+        self.f_tire_1 =  Polygon([(pos_x + self.length * 4.5 / 10, pos_y + self.width * 5 / 6),
+                                  (pos_x + self.length * 4.5 / 10, pos_y + self.width * 7 / 6),
+                                  (pos_x + 7.5 / 10 * self.length, pos_y + self.width * 7 / 6),
+                                  (pos_x + 7.5 / 10 * self.length, pos_y + self.width * 5 / 6)])
+        self.f_tire_2 =  Polygon([(pos_x + self.length * 4.5 / 10, pos_y - self.width * 5 / 6),
+                                  (pos_x + self.length * 4.5 / 10, pos_y - self.width * 7 / 6),
+                                  (pos_x + 7.5 / 10 * self.length, pos_y - self.width * 7 / 6),
+                                  (pos_x + 7.5 / 10 * self.length, pos_y - self.width * 5 / 6)])
+        self.r_axle =    Polygon([(pos_x, pos_y + self.width * 5 / 6),
+                                  (pos_x, pos_y - self.width * 5 / 6),
+                                  (pos_x, pos_y + self.width * 5 / 6)])
+        self.r_tire_1 =  Polygon([(pos_x + self.length * 1.5 / 10, pos_y + self.width * 5 / 6),
+                                  (pos_x + self.length * 1.5 / 10, pos_y + self.width * 7 / 6),
+                                  (pos_x - 1.5 / 10 * self.length, pos_y + self.width * 7 / 6),
+                                  (pos_x - 1.5 / 10 * self.length, pos_y + self.width * 5 / 6)])
+        self.r_tire_2 =  Polygon([(pos_x + self.length * 1.5 / 10, pos_y - self.width * 5 / 6),
+                                  (pos_x + self.length * 1.5 / 10, pos_y - self.width * 7 / 6),
+                                  (pos_x - 1.5 / 10 * self.length, pos_y - self.width * 7 / 6),
+                                  (pos_x - 1.5 / 10 * self.length, pos_y - self.width * 5 / 6)])
+
+    def draw(self, screen, car):
+        car_color = (181, 25, 253)
+        angle = -car.angle
+        steering = car.steering
+
+        car_model = rotate(self.car_model, angle, self.r_center)
+        x, y = car_model.exterior.xy
+        pygame.draw.polygon(screen, (0, 0, 255), [(xx, yy) for xx, yy in zip(x, y)])
+        f_axle = rotate(self.f_axle, angle, self.r_center)
+        x_axle, y_axle = f_axle.exterior.xy
+        pygame.draw.polygon(screen, car_color, [(xx, yy) for xx, yy in zip(x_axle, y_axle)], 2)
+        f_tire_1 = rotate(self.f_tire_1, angle, self.r_center)
+        f_tire_1 = rotate(f_tire_1, - steering, (x_axle[0], y_axle[0]))
+        x, y = f_tire_1.exterior.xy
+        pygame.draw.polygon(screen, (0, 0, 0), [(xx, yy) for xx, yy in zip(x, y)])
+        f_tire_2 = rotate(self.f_tire_2, angle, self.r_center)
+        f_tire_2 = rotate(f_tire_2, - steering, (x_axle[1], y_axle[1]))
+        x, y = f_tire_2.exterior.xy
+        pygame.draw.polygon(screen, (0, 0, 0), [(xx, yy) for xx, yy in zip(x, y)])
+        r_axle = rotate(self.r_axle, angle, self.r_center)
+        x, y = r_axle.exterior.xy
+        pygame.draw.polygon(screen, car_color, [(xx, yy) for xx, yy in zip(x, y)], 2)
+        r_tire_1 = rotate(self.r_tire_1, angle, self.r_center)
+        x, y = r_tire_1.exterior.xy
+        pygame.draw.polygon(screen, (0, 0, 0), [(xx, yy) for xx, yy in zip(x, y)])
+        r_tire_2 = rotate(self.r_tire_2, angle, self.r_center)
+        x, y = r_tire_2.exterior.xy
+        pygame.draw.polygon(screen, (0, 0, 0), [(xx, yy) for xx, yy in zip(x, y)])
+        rect = pygame.Rect(self.r_center[0], self.r_center[1], 5, 5)
+        pygame.draw.rect(screen, (255, 0, 0), rect)

Documentation/Projet/Simulation/2D-car-dynamics-simulation-master/car_model.py

+from pygame.math import Vector2
+from math import tan, radians, degrees, pi, atan2, sin, cos
+import numpy as np
+import random
+
+class Car:
+    def __init__(self, x, y, angle=0.0, length=5):
+        self.position = Vector2(x, y)
+        self.velocity = Vector2(0.0, 0.0)
+        self.angle = angle
+        self.length = length
+        self.width = 2
+        self.brake_deceleration = 30000
+        self.free_deceleration = 2
+
+        self.acceleration = Vector2(0, 0)
+        self.steering = 0.0
+        self.gear = 0
+        self.throttle = 0
+        self.brakes = 0
+        self.wheel_rpm = 0
+        self.rpm = 2000
+        self.angular_velocity = 0
+        self.force = Vector2(0, 0)
+
+        # Parts:
+        self.engine = Engine()
+
+        # Characteristics:
+        self.gears = {0: 0, 1: 3, 2: 2, 3: 1.5, 4: 1.25, 5: 1, 6: 0.75, -1: -2.9}
+        self.diff_ratio = 3.42
+        self.n = 0.8  # power transfer efficiency
+        self.wheel_radius = 0.35
+        self.mass = 1100
+        self.rear_wheels_mass = 100
+        self.c_drag = 0.4257
+        self.cornering_stiffness_f = -5.0
+        self.cornering_stiffness_r = -5.2
+        self.max_grip = 2.0
+        self.max_steering = 20
+
+    def get_driver_input(self, throttle, gear, brakes, steering_angle):
+        self.brakes = brakes
+        self.gear = gear
+        #on ajoute des vibrations
+        #self.steering+=random.randint(-5,5)
+        self.steering = steering_angle
+        self.throttle = abs(throttle)
+
+    def update(self, dt):
+        self.rpm = self.wheel_rpm * self.diff_ratio * self.gears[self.gear]
+
+        if self.rpm < 2000:
+            self.rpm = 2000
+
+        traction_force = self.engine.get_torque(self.rpm, self.throttle) * self.diff_ratio * \
+                         self.gears[self.gear] * (self.n / self.wheel_radius) - \
+                         self.brake_deceleration * self.brakes * np.sign(self.velocity.x)
+
+        resistance_force = Vector2(- self.c_drag * self.velocity.x * abs(self.velocity.x) - 12.8 * self.velocity.x,
+                                   - self.c_drag * self.velocity.y * abs(self.velocity.y) - 12.8 * self.velocity.y)
+
+        if self.velocity.x > 5.55:
+            yawspeed = 2 * self.angular_velocity
+
+            if self.velocity.x == 0:
+                rot_angle = 0
+                sideslip = 0
+
+            else:
+                rot_angle = atan2(yawspeed, self.velocity.x)
+                sideslip = atan2(self.velocity.y, self.velocity.x)
+
+            slipanglefront = sideslip + rot_angle - radians(self.steering)
+            slipanglerear = sideslip - rot_angle
+
+            flatf = Vector2(0, 0)
+            flatr = Vector2(0, 0)
+
+            flatf.x = 0
+            flatf.y = self.cornering_stiffness_f * slipanglefront
+            flatf.y = min(self.max_grip, flatf.y)
+            flatf.y = max(-self.max_grip, flatf.y)
+            flatf.y *= self.mass * 4.9
+
+            flatr.x = 0
+            flatr.y = self.cornering_stiffness_r * slipanglerear
+            flatr.y = min(self.max_grip, flatr.y)
+            flatr.y = max(- self.max_grip, flatr.y)
+            flatr.y *= self.mass * 4.9
+
+            self.force.x = traction_force + sin(radians(self.steering)) * flatf.x + flatr.x + resistance_force.x
+            self.force.y = cos(radians(self.steering)) * flatf.y + flatr.y + resistance_force.y
+
+            torque = 1.5 * (flatf.y - flatr.y)
+
+            self.acceleration = self.force / self.mass
+            self.wheel_rpm = self.velocity.x / self.wheel_radius * 30 / pi
+
+            self.velocity += self.acceleration * dt
+            self.position += self.velocity.rotate(-self.angle) * dt
+
+            angular_acceleration = torque / 1000
+            self.angular_velocity += angular_acceleration * dt
+            self.angle += degrees(self.angular_velocity) * dt
+
+        else:
+            self.force.x = traction_force + resistance_force.x
+            self.force.y = resistance_force.y
+            self.acceleration = self.force / self.mass
+            self.wheel_rpm = self.velocity.x / self.wheel_radius * 30 / pi
+
+            self.velocity += self.acceleration * dt
+            if self.steering:
+                turning_radius = self.length / tan(radians(self.steering))
+                angular_velocity = self.velocity.x / turning_radius
+            else:
+                angular_velocity = 0
+
+            self.position += self.velocity.rotate(-self.angle) * dt
+            self.angle += degrees(angular_velocity) * dt
+
+
+class Engine:
+    def __init__(self):
+        self.rpm_lut = np.array([1000, 2000, 3000, 4000, 5000, 6000, 7000, 8000, 9000])
+        self.torque_lut = np.array([200, 325, 475, 550, 550, 500, 375, 300, 0])
+
+    def get_torque(self, rpm, throttle):
+        if rpm < 1000:
+            rpm = 1000
+        torque = np.interp(rpm, self.rpm_lut, self.torque_lut)
+        return torque * throttle

Documentation/Projet/Simulation/2D-car-dynamics-simulation-master/errorFPS.json

+{
+    "time": [
+        0.2,
+        0.4,
+        0.6000000000000001,
+        0.8,
+        1.0,
+        1.2,
+        1.4,
+        1.5999999999999999,
+        1.7999999999999998,
+        1.9999999999999998,
+        2.1999999999999997,
+        2.4,
+        2.6,
+        2.8000000000000003,
+        3.0000000000000004,
+        3.2000000000000006,
+        3.400000000000001,
+        3.600000000000001,
+        3.800000000000001,
+        4.000000000000001,
+        4.200000000000001,
+        4.400000000000001,
+        4.600000000000001,
+        4.800000000000002,
+        5.000000000000002,
+        5.200000000000002,
+        5.400000000000002,
+        5.600000000000002,
+        5.8000000000000025,
+        6.000000000000003,
+        6.200000000000003,
+        6.400000000000003,
+        6.600000000000003,
+        6.800000000000003,
+        7.0000000000000036,
+        7.200000000000004,
+        7.400000000000004,
+        7.600000000000004,
+        7.800000000000004,
+        8.000000000000004,
+        8.200000000000003,
+        8.400000000000002,
+        8.600000000000001,
+        8.8,
+        9.0,
+        9.2,
+        9.399999999999999,
+        9.599999999999998,
+        9.799999999999997,
+        9.999999999999996,
+        10.199999999999996,
+        10.399999999999995,
+        10.599999999999994,
+        10.799999999999994,
+        10.999999999999993,
+        11.199999999999992,
+        11.399999999999991,
+        11.59999999999999,
+        11.79999999999999,
+        11.99999999999999,
+        12.199999999999989,
+        12.399999999999988,
+        12.599999999999987,
+        12.799999999999986,
+        12.999999999999986,
+        13.199999999999985,
+        13.399999999999984,
+        13.599999999999984,
+        13.799999999999983,
+        13.999999999999982,
+        14.199999999999982,
+        14.39999999999998,
+        14.59999999999998,
+        14.79999999999998,
+        14.999999999999979,
+        15.199999999999978,
+        15.399999999999977,
+        15.599999999999977,
+        15.799999999999976,
+        15.999999999999975,
+        16.199999999999974,
+        16.399999999999974,
+        16.599999999999973,
+        16.799999999999972,
+        16.99999999999997,
+        17.19999999999997,
+        17.39999999999997,
+        17.59999999999997,
+        17.79999999999997,
+        17.999999999999968,
+        18.199999999999967,
+        18.399999999999967,
+        18.599999999999966,
+        18.799999999999965,
+        18.999999999999964,
+        19.199999999999964,
+        19.399999999999963,
+        19.599999999999962,
+        19.79999999999996,
+        19.99999999999996,
+        20.19999999999996,
+        20.39999999999996,
+        20.59999999999996,
+        20.799999999999958,
+        20.999999999999957,
+        21.199999999999957,
+        21.399999999999956,
+        21.599999999999955,
+        21.799999999999955,
+        21.999999999999954,
+        22.199999999999953,
+        22.399999999999952,
+        22.59999999999995
+    ],
+    "x": [
+        1732.961286387469,
+        1732.1526264091385,
+        1732.3471681903861,
+        1732.2408878911015,
+        1732.1597730980216,
+        1731.5970807639185,
+        1732.0396357136551,
+        1731.5831140336522,
+        1730.9454885844018,
+        1734.4604226971344,
+        1710.2313881477512,
+        1723.0853565578536,
+        1697.834704882184,
+        1704.9171165268822,
+        1678.4674650048732,
+        1678.64617358835,
+        1663.8681485158445,
+        1677.2253629120341,
+        1659.5429674319553,
+        1676.8234346383222,
+        1679.837523146973,
+        1707.3913389356733,
+        1727.7523903942556,
+        1757.421682804023,
+        1787.335885374785,
+        1815.5525552677468,
+        1836.0759445730455,
+        1856.0091221624198,
+        1884.9167934953487,
+        1912.049440527352,
+        1942.359393049133,
+        1973.4653245132022,
+        2000.2245521430734,
+        2027.3009316476896,
+        2042.565440411347,
+        2057.353972013345,
+        2056.2946467356514,
+        2054.046605574749,
+        2036.8897779452925,
+        2018.089178819594,
+        2008.0105180571222,
+        1999.375186658567,
+        2002.2475343666129,
+        1988.2369020733113,
+        1976.7995089720039,
+        1953.973011362798,
+        1929.7211597303321,
+        1899.5702402493023,
+        1867.9716946644241,
+        1839.0043039469551,
+        1810.0664341767936,
+        1791.2983035107504,
+        1774.558776123896,
+        1771.986904334932,
+        1773.061556216539,
+        1762.9958341974534,
+        1751.7130695655565,
+        1731.1877905775837,
+        1724.096636962187,
+        1716.5814105065717,
+        1693.232796996565,
+        1694.1444414947143,
+        1668.549851619035,
+        1649.768271430797,
+        1619.4100763464303,
+        1588.6620350135713,
+        1558.277848130564,
+        1525.8603036490567,
+        1504.192002462834,
+        1481.9658148770195,
+        1475.8984474527151,
+        1471.8503301267024,
+        1457.4885976228659,
+        1441.155359570068,
+        1416.9122898253477,
+        1404.0629565734348,
+        1392.2228641542615,
+        1393.364326420527,
+        1398.8904431646479,
+        1416.6246744636996,
+        1439.384930225874,
+        1469.012913293123,
+        1501.2736313171504,
+        1533.2213225710068,
+        1563.529372043896,
+        1587.0287888184832,
+        1604.5808193286337,
+        1632.1733382809073,
+        1660.4355375317052,
+        1675.1436077784408,
+        1707.8152494287776,
+        1737.6869471112495,
+        1758.376854127139,
+        1778.1625434851464,
+        1783.9417070337638,
+        1785.4613324113277,
+        1773.1570712657503,
+        1772.863193044739,
+        1776.013025666458,
+        1788.9183082003865,
+        1808.394795928098,
+        1835.5562009425853,
+        1866.9903319383652,
+        1900.2721855594268,
+        1932.6749979835827,
+        1960.4521524084503,
+        1981.9814693167236,
+        1994.1972335397857,
+        1996.896181862177,
+        1988.9794825792592,
+        1971.7830231287653,
+        1963.9812514158043,
+        1960.9902151298913
+    ],
+    "y": [
+        -407.38574749946434,
+        -410.1450781792827,
+        -414.29637723334713,
+        -419.818127512097,
+        -426.71211840747475,
+        -434.9647822879525,
+        -444.59943904856783,
+        -455.58038002735066,
+        -467.91044947354226,
+        -481.442834320628,
+        -488.51871123137795,
+        -510.6809772390142,
+        -516.5700532944252,
+        -542.5218465339217,
+        -547.4461353722113,
+        -576.2700374912258,
+        -596.5567969953598,
+        -621.8927342720442,
+        -650.1798270897751,
+        -676.2700116023415,
+        -708.6531209885454,
+        -721.0133330771085,
+        -746.8476387905589,
+        -741.8178038711459,
+        -758.3850957433021,
+        -771.2982274243907,
+        -793.7167352819238,
+        -817.2932482633912,
+        -832.1131628686057,
+        -847.2890239621718,
+        -849.1416291299522,
+        -849.8532770923348,
+        -835.9452716692517,
+        -820.3526660927863,
+        -794.3060860117681,
+        -766.639332443908,
+        -736.3960864707866,
+        -704.9903533695303,
+        -679.9641880209497,
+        -654.5789391437684,
+        -623.1055836005652,
+        -592.6860125342031,
+        -561.8138535489933,
+        -530.9977671174613,
+        -501.20467805698325,
+        -480.07553076074544,
+        -459.4138034057579,
+        -452.9993001585988,
+        -448.5462631127082,
+        -459.2041936105157,
+        -472.7696039970146,
+        -497.3915321526512,
+        -524.6687568240793,
+        -555.626367429977,
+        -587.653089043164,
+        -619.9959728506324,
+        -650.3018007126493,
+        -674.4776916354847,
+        -708.1495163476111,
+        -739.854135446169,
+        -763.938113101683,
+        -798.3070504334978,
+        -821.5342579407381,
+        -849.0252828967887,
+        -858.0331750272223,
+        -870.9067994540502,
+        -863.1401210396791,
+        -855.9792400311505,
+        -833.1992064440471,
+        -808.7048856340194,
+        -777.7105267827612,
+        -744.9765338119622,
+        -713.6017626909212,
+        -684.8663918174944,
+        -663.3042435908567,
+        -630.735688199831,
+        -599.6288835560953,
+        -567.1823441927924,
+        -534.6369712723381,
+        -507.70916531776646,
+        -483.87948489298327,
+        -470.9629076346409,
+        -464.30916078072187,
+        -469.9462355403672,
+        -482.8678252494172,
+        -505.40692506178317,
+        -533.3151952232445,
+        -555.4528168518173,
+        -573.8224954223197,
+        -605.342527239041,
+        -618.2987266909263,
+        -635.0138534193854,
+        -662.7337669088829,
+        -690.2833230301019,
+        -722.6557520411346,
+        -756.3215540312655,
+        -786.717122358282,
+        -822.7297349496205,
+        -856.7275742126394,
+        -887.6215141972548,
+        -914.9837010446107,
+        -934.1482397721055,
+        -945.7574379704569,
+        -946.3635567071002,
+        -937.787339300482,
+        -919.289062000256,
+        -893.5545930254899,
+        -862.4046904032793,
+        -828.9163342544612,
+        -796.3228802290259,
+        -767.4021377154822,
+        -731.9563138296951,
+        -697.4870500671282
+    ]
+}
\ No newline at end of file
